10KW 12.5kva Small AC Brushless Alternator With H Insulation Class
Quick detail:
Name | ALTERNATOR | Brand Name | WERNA |
Color | According to the international standard color card | Feature | AC brushless synchronous excitation alternator |
Power | 10KW | Certificate | CE,ISO9001,SASO |
Specication:
manufacture | Wuxi City ,Jiangsu Prov ,China making alternators |
Output type | AC Three Phase Brushless generator |
Terminal | 12 / 6 Wire |
Rated Voltage | 190V~454V |
Frequency | 50Hz |
Speed | 3000RPM |
Mounting Dimension | Stamford Type |
Winding pitch | 2/3 pitch |
Excitation | Brushless, self-excited, synchro |
Insulation Class | H |
Description:
1) Protection class IP23, insulation class H.
2) The standard winding protection can accept up to 95% relative
humidity and the alternator is suitable for indoors marine
applications.
3) The brushless alternator is equipped with reliable AVR. MX321,
MX341, AS440, SX440, SX460, etc
4) Adapted to excitation systems, powered by transistors and
fulfilling perfect regulation.
5) The power factor ranges from 0.8 to 1.
6) Telephone influence factor is less than 50, according to NTMA.
7) Transient voltage dip for rated step load at 0.8 power factor is
less than 18%.
8) Overload standard according to NEMA.
9) All generator statore are wound to 2/3 pitch.
Frequency And Voltage
50Hz or 60Hz as per customer's request. Voltage from 380 ~ 690V,
190V~345V, 220~400V, serial star, parralle star and serial delta
connection are available, All three-phase generators are 12-lead
reconnectable, providing voltage and phase flexibility.
Insulation and Protection
Insulation: H, Protection: IP22
Voltage Regulators
The model we use including: MX321, MX341, AS440, SX440, SX460, etc.
Winding
All generator stators are wound to 2/3 pitch
FAQ:
1. Q: When was your company established?
A:in 2005
2. Q: What is your main products?
A: Alternator
3. Q: What certificate you get?
A: We pass ISO9001 and approved by CE.
4. Q: What is your MOQ of this item?
A: 1-10PCS
5. Q: What is the lead time?
A: 25-30 days after receiving your L/C or TT deposit.
6. Q: Is it all right to make customer's own brand name?
A: We can be your OEM manufacture with your authorization of brand.
7. Q: Where is your Loading Port?
A: Shanghai, China Port.
8. Q: What are your payment terms?
A: 30% deposit and balance T/T against copy of Bill of Lading or
L/C at sight.
9. Q: What is your company's available production capacity?
A: 3000-5000 pieces against your orders.
